Deck Height Lever Assembly
Parts Index
- 6 1/4-20 Nylon Insert Flange Nut (Qty 1)
- 9 3/8-16 Nylon Insert Locknut Zi (Qty 3)
- 11 3/8 Nylock Flange Nut (Qty 4)
- 19 5/16-18 Nylon Flange Nut (Qty 2)
- 23 5/16-18 Hex Flange Nuts Zinc w (Qty 2)
- 40 Pillow Block (Qty 2)
- 40.1 2017 Magnum Pillow Block-Male (Qty 2)
- 40.3 2017 Magnum Pillow Block-Metal Plate (Qty 1)
- 48 1/2-13 x 6 1/2 Hex Bolt Grade 5 (Qty 2)
- 65 10mm Damper Ball Stud- (Qty 1)
- 66 10mm Ball Stud (Long Thread) (Qty 1)
- 68 5/8 x 5/8 Shoulder Bolt (Qty 6)
- 70 1/2-13 Nylon Insert Jam Locknut (Qty 8)
- 100 1/2 Flat Washer (Qty 4)
- 106 .630 ID X 1.122 OD X .142 THK (Qty 2)
- 124 1/8" Drive-in Grease Fitting No Ball (Qty 3)
- 175 2019 Stand On Deck Lever Lock--Black (Qty 1)
- 261 Grip (Deck Lift) (Qty 1)
- 274 Band 13.5" (Qty 2)
- 295 Dampener (200lbs) (Qty 1)
- 296 Dampener (250lbs) (Qty 1)
- 340 2023 Revolt Lift Lever--Orange (Qty 1)
- 341 Lever Secondary Linkage--Black (Qty 1)
- 344 Revolt Spacer 2.5" (Qty 2)
- 346 3/8’’-16 x 3 ¾’’ Hex bolt Grade 5 (Qty 3)
- 352 2023 Revolt Tank (Qty 1)
- 353 2023 Stand On Actuator Linkage--Black (Qty 2)
- 354 Bronze Bushing - SF-2024-8 (Qty 6)
- 373 Fuel Cap for 2023 48"/54"/61" Revolt (Qty 1)
- 374 2023 Revolt Deck Height Pin (Qty 1)
- 384 Revolt Deck Height Indicator (Qty 1)
- 389 Front Actuator Bar Weldment--Black (Qty 1)
- 390 Rear Actuator Bar Weldment-RH-Black (Qty 1)
- 391 Rear Actuator Bar Weldment-LH--Black (Qty 1)
- 438 Stand On Spacer 2.5" With Shoulder (Qty 1)
- 441 3/8x2 1/2" Hex Bolt (Qty 4)
- 443 5/16-18 X 1-1/4 Carriage Bolt (Qty 2)
-
6#013-2050-00
1/4-20 Nylon Insert Flange Nut
Qty Used: 1Regular price $1.39 USDRegular priceUnit price per
-
9#013-5041-00
3/8-16 Nylon Insert Locknut Zi
Qty Used: 3Regular price $0.69 USDRegular priceUnit price per
-
11#013-5202-00
3/8 Nylock Flange Nut
Qty Used: 4Regular price $1.49 USDRegular priceUnit price per
-
19#013-8049-00
5/16-18 Nylon Flange Nut
Qty Used: 2Regular price $0.79 USDRegular priceUnit price per
-
23#013-9002-00
5/16-18 Hex Flange Nuts Zinc w
Qty Used: 2Regular price $0.69 USDRegular priceUnit price per
-
40#017-9076-00
Pillow Block
Qty Used: 2Regular price $21.88 USDRegular priceUnit price per
-
40.1#017-9077-00
2017 Magnum Pillow Block-Male
Qty Used: 2Regular price $19.89 USDRegular priceUnit price per
-
40.3#017-9079-00
2017 Magnum Pillow Block-Metal Plate
Qty Used: 1Regular price $19.89 USDRegular priceUnit price per
-
48#018-0038-00
1/2-13 x 6 1/2 Hex Bolt Grade 5
Qty Used: 2Regular price $2.69 USDRegular priceUnit price per
-
65#018-2050-00
10mm Damper Ball Stud-
Qty Used: 1Regular price $1.99 USDRegular priceUnit price per
-
66#018-2055-00
10mm Ball Stud (Long Thread)
Qty Used: 1Regular price $1.99 USDRegular priceUnit price per
-
68#018-3001-00
5/8 x 5/8 Shoulder Bolt
Qty Used: 6Regular price $14.59 USDRegular priceUnit price per
-
70#018-4010-00
1/2-13 Nylon Insert Jam Locknut
Qty Used: 8Regular price $1.59 USDRegular priceUnit price per
-
100#019-2040-00
1/2 Flat Washer
Qty Used: 4Regular price $1.39 USDRegular priceUnit price per
-
106#019-6017-00
.630 ID X 1.122 OD X .142 THK
Qty Used: 2Regular price $0.79 USDRegular priceUnit price per
-
124#024-3050-00
1/4" Drive-in Grease Fitting
Qty Used: 3Regular price $0.99 USDRegular priceUnit price per
-
175#031-0093-00
2019 Stand On Deck Lever Lock--Black
Qty Used: 1Regular price $22.54 USDRegular priceUnit price per
-
261#069-4012-00
Grip (Deck Lift)
Qty Used: 1Regular price $13.26 USDRegular priceUnit price per
-
274#072-0051-00
Band 13.5"
Qty Used: 2Regular price $10.60 USDRegular priceUnit price per
-
295#087-5400-00
Damper (200lbs)
Qty Used: 1Regular price $58.32 USDRegular priceUnit price per
-
296#087-6100-00
Dampener (250lbs)
Qty Used: 1Regular price $72.91 USDRegular priceUnit price per
-
340#031-7153-00
2023 Revolt Lift Lever--Orange
Qty Used: 1Regular price $69.95 USDRegular priceUnit price per
-
344#025-5343-00
Revolt Spacer 2.5"
Qty Used: 2Regular price $10.29 USDRegular priceUnit price per
-
346#018-0084-00
3/8’’-16 x 3 ¾’’ Hex bolt Grade 5
Qty Used: 3Regular price $1.49 USDRegular priceUnit price per
-
352#067-0030-23
2023 Revolt Tank
Qty Used: 1Regular price $475.00 USDRegular priceUnit price per
-
354#032-5052-00
Bronze Bushing - SF-2024-8
Qty Used: 6Regular price $4.37 USDRegular priceUnit price per
-
373#066-8070-00
Fuel Cap for 2023 48"/54"/61" Revolt
Qty Used: 1Regular price $29.99 USDRegular priceUnit price per
-
374#040-4004-00
2023 Revolt Deck Height Pin
Qty Used: 1Regular price $14.99 USDRegular priceUnit price per
-
384#091-0025-00
Revolt Deck Height Indicator
Qty Used: 1Regular price $14.99 USDRegular priceUnit price per
-
391#028-0048-00
Rear Actuator Bar Weldment-LH--Black
Qty Used: 1Regular price $59.99 USDRegular priceUnit price per
-
438#025-0081-00
Stand On Spacer 2.5" With Shoulder
Qty Used: 1Regular price $13.99 USDRegular priceUnit price per
-
441#018-0028-00
3/8x2 1/2" Hex Bolt
Qty Used: 4Regular price $3.99 USDRegular priceUnit price per
-
443#018-4703-00
5/16-18 X 1-1/4 Carriage Bolt
Qty Used: 2Regular price $0.69 USDRegular priceUnit price per
