Pump Plate Subs

Parts Index
- 44 5/16-18 x 2.25" Hex Bolt Gr 5 (Qty 2)
- 128 2019 Brake Handle Spacer .625 x 1.5 (Qty 2)
- 168.1 Cast Pump Pulley - 17mm Assembly (Qty 1)
- 168.2 5/16-18 X 1/2 SOCKET SET SCREW KNURLED CUP POINT (Qty 1)
- 191 2020 Diesel Pump Tensioner Assembly LH (Qty 1)
- 191.1 3/8-16 Hex Flange Nuts Zinc w/ (Qty 1)
- 191.2 3/8 Nylock Flange Nut (Qty 1)
- 191.3 1/2-13 Nylon Insert Flange Nut (Qty 1)
- 191.4 1/2-13 x 2 Grade 8 Hex Bolt (Qty 1)
- 191.5 3/8 x 1 1/2 Bolt (Qty 1)
- 191.6 1/2 Set Collar w/set collar (Qty 1)
- 191.7 Bronze Bushing - SF-2024-8 (Qty 2)
- 191.8 4 3/4 Idler Pulley - ABFI-76 (Qty 1)
- 191.9 OBSOLETE USE 039-6950-01 (Qty 1)
- 192 2020 Diesel Pump Tensioner Assembly RH (Qty 1)
- 192.1 3/8-16 Hex Flange Nuts Zinc w/ (Qty 1)
- 192.2 3/8 Nylock Flange Nut (Qty 1)
- 192.3 1/2-13 Nylon Insert Flange Nut (Qty 1)
- 192.4 3/8 x 1 1/2 Bolt (Qty 1)
- 192.5 1/2-13 X 2-3/4 GR 5 Bolt Zinc (Qty 1)
- 192.6 1/2 Set Collar w/set collar (Qty 2)
- 192.7 Bronze Bushing - SF-2024-8 (Qty 2)
- 192.8 4 3/4 Idler Pulley - ABFI-76 (Qty 1)
- 192.9 OBSOLETE USE 039-6950-01 (Qty 1)
- 205 2019 Rogue/Renegade Left Pump 16cc (Qty 1)
- 205.1 Fan Guard 6" - Fits Wheel (Qty 1)
- 205.2 Hydro Fan - Light/Pup/Outlaw XP (Qty 1)
- 206 Renegade Right Pump 16cc (Qty 1)
- 206.1 Fan Guard 6" - Fits Wheel (Qty 1)
- 206.2 Hydro Fan - Light/Pup/Outlaw XP (Qty 1)
